Appendix – Specifications
Power Considerations
186 Strata CIX General Description 04/13
Power Considerations
CIX40
CIX100
The power supply in each CIX100 Base and Expansion Cabinet furnishes power to all of the
stations and some of the interface peripherals (see Table 31). The primary AC power for each
cabinet is 120VAC.
CIX200
Table 30 CIX40 Electrical Characteristics
CIX40 Primary Power
Input AC (Power Supply Specification)
AC frequency
Power
AC input current
120~240VAC
50/60 Hz
CIX40 - 100 watts maximum
1.3A maximum (100 VAC)
Power
Input DC 15V use the factory-shipped AC adapter
Power Converter
DC voltage output specification -24VDC (-26.3 ~ -28.3VDC)
+5VDC (+4.5 ~ +5.5VDC)
Standard Telephone Ring Circuit (GMAU2 and GSTU1)
Ring Voltage 180V p-p square wave
Ringing capability 1 REN, 1 circuit - one telephone per circuit
Table 31 CIX100 Electrical Characteristics
CIX100 Primary AC Power Voltage
Input AC
AC Frequency
Watts per cabinet (maximum)
120VAC
60 Hz, Single-phase (48Hz~62Hz)
100 watts (maximum)
CIX100 Primary Power Current Consumption (Rating in Amperes)
120VAC
1 cabinet
2 cabinets
1.8 amps
3.6 amps
Power Supply Unit (APSU112A)
DC voltage output specification -24VDC (-26.3~-27.8VDC, 3.2 DC amps)
+5VDC (+4.5~5.5VDC, 2.0 DC amps)
-5VDC (-4.5~-5.5VDC, 0.2 DC amps)
+3.3VDC (+3.0~3.6VDC, 0.5 DC amps
Table 32 CIX200 Electrical Characteristics
CIX200 Primary AC Power Voltage
Input AC
AC Frequency
Watts per cabinet (maximum)
120VAC, 4.0 amps max.
Single-phase (45Hz~65Hz)
480 watts (maximum)
