Appendix – Specifications
Strata CIX Component Compatibility
192 Strata CIX General Description 04/13
Voice Mail CIX40 CIX100 CIX200 CIX670 CIX1200
Stratagy ES Standalone Models X X X X X
Stratagy iES32 and iES16 NC X X X X
LVMU1A NC X X X X
GVPH1A X NC NC NC NC
Attendant Consoles CIX40 CIX100 CIX200 CIX670 CIX1200
Strata CIX IP Attendant Console (Requires
MIPU/LIPU/LIPS/GIPU/GIPH)
XXX X X
Strata CIX Digital Attendant Console (Digital
Telephone Port connection)
XXX X X
Maximum Capacities CIX40 CIX100 CIX200 CIX670 CIX1200
KSU Cabinets (base plus expansion) 1 2 2 7 12
Base Cabinet PCB Slots 4 4 3 8 8
Expansion Cabinet PCB Slots 0 4 4 10 10
Total System PCB Slots 4 8 7 68 118
Trunk/Station/Voice mail Ports 57 112 192 672 1152
Trunk Lines 11 64 96 264 440
IP Telephones (IP5000-series/IPT2000-series)
11
24 72 160 560 1000
Strata Net Channels 24 48 96 264 440
Digital Telephones (DP5000-series, DKT2000,
3000/3200)
16 72 112 560 952
Analog Standard Telephones 2 56 58 544 944
Ethernet LAN CIX40 CIX100 CIX200 CIX670 CIX1200
AETS (Used for the ACTU1 on the CIX 100,
built-in on the other ACTU processors)
Built-in ACTU1 Built-in Built-in Built-in
V.34 Admin Modem CIX40 CIX100 CIX200 CIX670 CIX1200
AMDS NC X X X X
Base Cabinet CIX40 CIX100 CIX200 CIX670 CIX1200
CHSUB672 NC NC NC X X
CHSUB112 NC X NC NC NC
CHSUB192A NC NC X NC NC
CHSU40A X NC NC NC NC
CHSU40A2 X NC NC NC NC
Expansion Cabinet CIX40 CIX100 CIX200 CIX670 CIX1200
CHSUE672 NC NC NC X X
CHSUE112 NC X NC NC NC
CHSUE192A NC NC X NC NC
Data Cable for CIX670 Expansion Cabinet NC NC NC X X
Data Cable for CIX100 Expansion Cabinet NC X NC NC NC
Data Cable for CIX200 Expansion Cabinet NC NC X NC NC
Power Supply Unit CIX40 CIX100 CIX200 CIX670 CIX1200
BPSU672 (120VAC/208VAC/240VAC power
supply)
NC NC NC X X
APSU112 (120VAC) NC X NC NC NC
Conduit Connection Box CIX40 CIX100 CIX200 CIX670 CIX1200
RCCB2 NC NC NC NC NC
BCCB120 (120V box) NC NC NC X X
BCCB240 (240V box) NC NC NC X X
Battery Distribution Box CIX40 CIX100 CIX200 CIX670 CIX1200
BBDB1 (new Battery Dist. Box, 7 BBTC2A-2.0M) NC NC X X X
Table 41 Component Compatibility (continued)
