Appendix – Specifications
Station Dimensions
Strata CIX General Description 04/13 199
Station Dimensions
Dimensions for the 3000-series, IPT telephones and related equipment are listed in Table 47.
Table 47 Station Dimensions
Device
Height Width Depth
Inches mm Inches mm Inches mm
IP5022-SD, IP5122-SD, IP5122-SDC, IP5132-SD, IP5522-
SD, IP5622-SD, IP5131-SDL [15-degree tilt], IP5631-SDL
5.1 129 10.16 258 6.10 155
IP Direct Station Selection (DSS) Console - IDM5060
[15-degree tilt]
4.0 102 10.16 258 6.10 155
DP5018-S, DP5022-SDM, DP5022-SD, DP5122-SD,
DP5032-SD, DP5132-SD, DP5130-SDL, DP5130-FSDL
[15-degree tilt]
5.1 129 10.16 258
6.10 155
Single Line Telephone (DP5008) [15-degree tilt]
3.86 98 5.9 150
Add-on Module (KM5020, LM5110) [15-degree tilt]
4.0 102
3.54 90
Direct Station Selection (DSS) Console (DDM5060)
[15-degree tilt]
10.16 258
10-button IP Telephone with LCD (IPT2010-SD)
20-button IP Telephone with LCD (IPT2020-SD)
8-button IP Telephone with large LCD (IPT2008-SDL)
4.5 115 7.8 198
9.6 245
Add-on Module (IADM2020
3.8 96.5 2.8 70
Direct Station Selection (DSS) Console (IDSS2060)
3.8 96.5 7.8 198
20-button IP Telephone with LCD (IPT1020-SD)
4.0 101.5 8.1 205
9.3 in. 235
Digital Single Line Telephone (DKT3001)
4.0 101.5 5.9 150
Add-on Module (DADM3020, DADM3120)
3.5 88 2.8 70
Direct Station Selection (DSS) Console (DDSS3060)
3.5 88 8.1 205
Handset with Handset Cradle (BATHC)
2.9 73 2.8 71 9.6 244
10-button DKT with Handsfree Answerback (DKT2010-S)
4.1 104 7.7 195 9.1 230
10-button DKT with LCD (DKT2010-SD)
20-button DKT (DKT2020-S)
20-button DKT with LCD (DKT2020-SD)
20-button DKT with LCD (DKT2020-FDSP)
Digital Single Line Telephone (DKT2001)
4.2 107 5.5 140 9.1 230
Add-on Module (DADM2020)
3.3 85 2.8 70 9.1 230
Direct Station Selection (DSSS2060) Console
3.3 85 7.8 199 9.1 230
External Speaker Amplifier (BESCB)
10.2 260 10.2 260 4.9 125
Door Phone/Lock Control Unit (DDCB)
4.7 120 6.5 165 1.5 38
Door Phone (MDFB)
5.5 140 3.1 80 1.3 32
Attendant Console Interface (BATI)
1.7 42.4 5.0 126 7.3 185
DKT2404-DECT Digital Cordless Telephone
Height Width Depth
Inches mm Inches mm Inches mm
Base
5 127 8.5 216 2.25 57.15
Handset
6.5 165 2.25 57.15 1.0 25.4
DKT2204-CT Digital Cordless Telephone
Height Width Depth
Inches mm Inches mm Inches mm
Base
2.0 50.8 2.75 69.85 2.813 71.45
Handset (with antenna)
8.66 219.96 2.2 55.89 1.66 42.16
DKT2304-CT Digital Cordless Telephone
Height Width Depth
Inches mm Inches mm Inches mm
Base
2.25 57.15 4.25 107.95 7.625 193.67
Handset (with antenna)
5.5 139.7 2.0 50.8 1.25 31.75
