Appendix – Specifications
Reserve Power
Strata CIX General Description 04/13 189
Table 39 CIX670 and CIX1200 Typical Reserve Power Duration Estimates
1
1. Assumes 80 ampere-hours with 12VDC batteries.
Number of Cabinets 1 2 3 4 5 6 7
Estimated operation time
Two-battery
configuration
12.0 hr. 6.0 hr. 4.0 hr. 3.0 hr. 2.5 hr. 2.0 hr. 1.8 hr.
Estimated operation time
Four-battery
configuration
24.0 hr. 12.0 hr. 8.0 hr. 6.0 hr. 5.0 hr. 4.0 hr. 3.5 hr.
DC Current Drain
(-24VDC)
4.6 amps. 8.7 amps.
12.8
amps.
16.9
amps.
21.0
amps.
25.1
amps.
29.2
amps.
Table 40 CIX1200 Typical Reserve Power Duration Estimates
1,2
1. Assumes 80 ampere-hours with 12VDC batteries.
2. Reserve power treatment for CIX1200 should be configured as two separate sys-
tems – one 7-cabinet stack and one 5-cabinet stack.
Number of Cabinets 8 9 10 11 12
Estimated operation time
Two-battery
configuration
12.0 hr. 6.0 hr. 4.0 hr. 3.0 hr. 2.5 hr.
Estimated operation time
Four-battery
configuration
24.0 hr. 12.0 hr. 8.0 hr. 6.0 hr. 5.0 hr.
DC Current Drain
(-24VDC)
4.6 amps. 8.7 amps.
12.8
amps.
16.9
amps.
21.0
amps.
