Strata CIX40
System Configuration
10 Strata CIX General Description 04/13
Table 3 CIX40 R2 Cabinet Configurations (CHSU40A2 Cabinet/R5.1 SW)
Analog
CO Lines
Digital
Telephones
IP Channels Equipment
4 8 0 Cabinet (CHSU40A2)
7 16 0 Cabinet, GCDU2A
8 8 0 Cabinet, GCOCIH
11 16 0 Cabinet, GCDU2A, GCOCIH1A
4 8 8, 16, 24 Cabinet, GIPU, GIPH1A, MIPU161A, MIPU241A
7 16 8, 16, 24
Cabinet, GCDU2A, GIPU, GIPH1A, MIPU16,
MIPU24
Voice Mail: GVPH1A can be installed in all of the above configurations to provide 4 default VM
Ports and expand to 6 or 8 VM Ports with the LIC2-GVPH license
Analog FX/Modem Ports: One analog station port is standard on the Base cabinet;
a second can be added by installing GSTU1A.
Table 4 CIX40 R1 Cabinet Configurations (CHSU40A Cabinet/R5.1 SW)
Analog
CO Lines
Digital
Telephones
IP Channels Equipment
3 8 0 Cabinet (CHSU40A)
6 16 0 Cabinet, GCDU2A
7 8 0 Cabinet, GCOCIH
10 16 0 Cabinet, GCDU2A, GCOCIH1A
3 8 8, 16 Cabinet, GIPU8, GIPH1A, MIPU16
6 16 8, 16 Cabinet, GCDU2A, GIPU8, GIPH1A, MIPU16
Voice Mail: GVPH1A can be installed in all of the above configurations to provide 4 default VM
Ports and expand to 6 or 8 VM Ports with the LIC2-GVPH license
Analog FX/Modem Ports: One analog station port is standard on the Base cabinet;
a second can be added by installing GSTU1A.
