DP5000-series Digital Telephones
46 Strata CIX General Description 04/13
DP5000-series Telephone Illustrations
Legend
A. Status LED (message and ringing)
B. LCD Display
C. Softkeys
D. Programmable Feature Buttons
E. Message Waiting LED Button
F. Microphone LED Button
G. Speaker LED Button
H. Volume
I. Hold Button
J. Microphone
K. Tilt stand
L. Off-Hook Button (Single Line
Telephone)
20 Programmable Feature Buttons 4-Line LCD Telephone
A
B
C
E
F
G
H
I
J
K
D
Single Line Telephone 1 Programmable Button
A
D
H
I
E
L
G
