8 BA_VEB200-1-2_A2_180618_en
2.4
Recommended rated speed 1800 min
-1
Technical data
Machine pulley diameter dw 71 mm
Min. sewing drive power 550 W
Toothed belt pulley/machine Z = 20
Toothed belt profile HTD 5M-15
Stitch length-upper feed 4 - 7 mm
(depend on fabric)
Kind of stitch single thread chain stitch bluff edge blind stitch
Stitch type 105
Needle system GROZ-BECKERT 1669 EEO
Needle size 80
Thread polyester continuous filament
Thread size 200/2
Pneumatic connection 6 bar
Average air consumption depending on the equipement
Required space 0.5 m x 1.1 m
Noise:
Average noise level at a speed of
n = 1800 min
-1
: LpAm 70 dB (A)
Noise test according to DIN 45635-48-1 KL3
