8 BA_VTD410EV_A2_180706_en
2.4 Technical data
Recommended rated speed 1500 min
-1
Motor power 600 W
Toothed belt pulley/machine Z = 38
Toothed belt profile HTD 5M-9
Stitch length 3 – 8 mm
Kind of stitch single thread overseam
Stitch type 501
Needle system GROZ-BECKERT 134
Needle size 160
Thread polyester continuous filament
Thread size 30
Kind of feed rear and front cup drive
Pneumatic connection 10 bar
Working pressure 5 – 6 bar
Air consumption – average value depending on the equipement
Required space 0.7 x 1.06 m
Noise:
Average noise level at a speed of
n = 1500 min
-1
: LpAm 77 dB (A)
Noise test according to DIN 45635-48-1 KL3
