22 BA_VTD410EV_A2_180706_en
4.5 Setting the stitch length
ATTENTION!
Switch off the machine electrically and make sure that the
machine is really in standstill position by stepping the
treadle for the motor control before setting the stitch
length. Otherwise: DANGER of finger bruises and needle
through stitches/punctures.
As shown in Fig. 13, the stitch length can be regulated with the stitch regulating
knob (1) in the left handwheel by turning it to the left or to the right up to the
limit stop. The stitch length can be regulated from approx. 3.0 to 8.0 mm.
Turning to the left results in a shorter stitch.
Turning to the right results in a longer stitch.
Fig. 13
