4.3 Threading - thread course (Fig. 9 and Fig. 10)
ATTENTION!
Switch off machine electrically and make sure that the
machine is really in the standstill position by stepping the
treadle for the motor control before threading. Otherwise:
DANGER of finger bruises and needle through
stitches/punctures.
ATTENTION!
The "preparation threading" replaced
not
the electrical shutdown of the machine when threading.
The function is only to the needle when turning off of the
machine is already in the correct position.
4.3.1 Threading
For safety reasons the function “Threading” has to be activated before
threading the machine. The button “4” at the control panel V810 is activating
the function “Threading” and an arrow in the display above the button indicate
the activation.
All electronically controlled functions are blocked and cannot be activated.
(Please see the operating instruction manual for the sewing drive).
4.3.2 Thread course (Fig. 11 and Fig. 12)
Because of the pneumatically controlled gathering device two successive
Asked thread tensions are grown. The front tension (4) operating normally, the
rear thread tension (5) activity occurs when the partition plate of Gathering
device swung and fullness, as is gathered at the toe. For this shirring a firmer
tension is needed to better fix the resulting material folds on the shoe sole, and
can get a good gathering. After swinging the partition plate, the front is now
more normal tension back into activity and that the rear thread tension is
released.
