Strom SSRTPR05 - Wiring Diagram

22
DELIVERING THE POWER
STROM LIMITED
When wiring your backplate up, or performing maintenace on the backplate
please ensure that all the mains AC supply has been isolated.
We recommend that all wiring is done with 1.0mm
2
or 1.5mm
2
cabling, and
that care is taken to ensure good connection with the terminals.
Backplate wiring view
Electrical wiring schematic
INSTALLATION GUIDE
WIRING DIAGRAM
COMMON
OFF
ON
1 2 3
Fused 6A
Max
COM NO NC
