16
Problem Possible cause and solution
The remote control
does not work
1. hange the batteries. If you're using rechargable ones take care to use such with low self-
discharge
2. The batteries are not installed correctly or the types have been mixed
3. IR Sensor is blocked or maybe interfered from bright light
after a certain time
Switch ON the TV and check settings for automatic STBY function, by default the TV switches OFF after 4
NOTE: If the problem persists after these solutions, please contact your local support centre or send a support mail via our
website www.strong-eu.com.
8.0 SPECIFICATIONS
Audio
Audio Output: 2 W
Video
DVB-T: Reception range: VHF (174MHz ~ 230MHz), UHF (474MHz ~ 862MHz)
Input impedance: 75Ω
Channel Bandwidth: 7MHz/8MHz
Modulation: DVB-T: COFDM 2K/8K QPSK,16QAM,64QAM
DVB-S/S2: QPSK ,8PSK
DVB-T2: QPSK,16QAM,64QAM,256QAM
DVB-C: 16QAM, 32QAM, 64QAM, 128QAM, 256QAM
Video System:
depth, 1920x1080@60fps
Sound System: MPEG-1 layer 1/2
System: DTV: DVB-T2, DVB-S2, DVB-C, DVB-T, DVB-S
ATV: PAL/SECAM/ NTSC
AV: PAL, NTSC
Connectors
1x ANT IN
1x SAT IN
2x HDMI
1x USB
1x S/PDIF (optical)
1x AV IN
1x COMMONINTERFACE (CI)
1x Headphones
1 x 12Volt DC IN
General Data
Power adaptor voltage: 180 ~ 240 V AC 50/60 Hz
Operating voltage: 12Volt / 4Ampere max.
Power consumption: SRT24HE4023: 45W / 50W
SRT24HE4023C: 45W / 48W
Operating temperature: 5 °C ~ +35 °C
Storage temperature: -15 °C ~ +45 °C
Operating humidity: 0% ~ 80% RH, non-condensing
Storage humidity: 0% ~ 90% RH, non-condensing
Dimensions (WxHxD) in mm: SRT24HE4023: 552.9 x 144.1 x 369.7
SRT24HE4023C: 552.9 x 147.8 x 369
Net-weight:
2.5 kg
