SECURITY GRID OPERATING INSTRUCTIONS (OPTIONAL) - PAGE #1 of 2
NOTE:
ILLUSTRATIONS
MAY NOT
EXACTLY
REFLECT EVERY
PARTICULAR
CASE’S
FEATURES
Initial Positioning and Installation of Security Grid
1. After hoisting the Security Grid directly over Air Return Cover, drop Security Grid
Positioning Rods into the Air Return Cover Holes (see enlarged view below).
2. After securely positioned in the Air Return Cover Holes, carefully and slowly lean
the Security Grid back against the Security Brackets.
3. The next page in this manual will show how to secure the top of the Security Grid
to the Security Brackets.
Air Return
Cover Hole
20
Enlarged View (Above)
Enlarged View (above) shows Security Grid
Positioning Rod slid into Air Return Cover Hole.
There are two Security Grid Positioning Rods along
each Security Grid.
Security Grid Positioning Rods must be securely in
place prior to locking with Padlocks.
Security Grid
Positioning Rod
To Next Page
