10
Item Description Qty. REF
A Vacuum Hood Ass'y 1 940-1-134
B Output Drive Ass'y 1 940-1-125
C O-ring 1 45-29
D Screw 4 50-33
E Lock Washer Ext. 4 12-24
F Cup Washer 1 940-1-115
G Bowed Retaining Ring 1 28-109
H Dogpoint Set Screw 1 21-129
I Blade Retention Screw 1 940-1-118
J Roller Bearing 1 81-118
K Washer 2 11-275
L Retaining Ring 1 28-111
M Brush 2 940-1-113
N Spring 2 38-49
O Brush Cap 2 58-18
P Blade Tool 1 940-50
Q Vacuum Line Cap 1 940-1-135
Replacement Parts Assembly
WARNINGS:
• Disconnect from electrical supply before servicing.
• Test leakage current after replacing brushes. See Periodic Maintenance for details.
• Use only identical replacement parts.
Replacement Parts List
