Features (continued)
Function Switch
SAFETY – Fully depress the
switch to lock both triggers.
FORWARD – Center the switch
to lock the reverse trigger. The
forward trigger is functional.
FORWARD/REVERSE – Fully
extend the switch to unlock
both triggers. Both triggers are
functional.
Definitions
The symbols located on the equipment and/or labeling are defined
in this section or in the Symbol Definition Chart. See the Symbol
Definition Chart supplied with the equipment.
SYMBOL DEFINITION
REVERSE TRIGGER
FORWARD TRIGGER
SAFETY
FORWARD
FORWARD/REVERSE
Cord Alignment Mark
