12
Model: REF 4207 Recip/Sternum Saw
Size: 7.4 in. [188mm] height (with battery)
1.5 in. [38.1mm] width
7 in. [178mm] length (without sternum blade guard)
Weight: 2.5 lbs. [1.13kg] (with battery, but without sternum blade guard)
Speed: 11,000 CPM
Excursion: 0.152 in. [3.9mm]
Duty Cycle: Intermittent Operation - 1 minute on / 4 minutes off 5 times
with a 3 hour rest
Approvals: CSA International
CAN/CSA-C22.2 No. 601.1-M90
UL 60601-1
IEC 60601-1
Equipment Type: Type BF Applied Part
Power Supply: Internally Powered
Enclosure Protection: IPX0 Ordinary Equipment
Environmental Conditions: Operation Storage and Transportation
Temperature:
Relative Humidity:
Atmospheric Pressure:
*Specifications listed are approximate and may vary slightly from unit to unit or by power supply fluctuations.
Specifications*
