NNaammee FFuunnccttiioonn
AA Chair exit alarm
Illuminates green when you arm the chair exit system.
Flashes yellow and triggers an audible alarm when an
occupant exits the chair.
BB
Chair alarm arm/disarm
Press once to arm the chair exit system. Press again to
disarm the chair exit system.
• The minimum occupant weight required to detect an
occupant to arm the chair exit system is 65 lb
• Stand Assist, Full-Flat Transfer and Trend positions
are unavailable when you arm the chair exit system
• The chair exit system will only arm when in the
Upright 1, Upright 2, and Recline positions and
when you apply the parking brake
• The chair exit system alarm continues to sound until
you press arm/disarm
CC Stand Assist
Provides lift assistance for occupants who may have
difficulty rising from a seated to a standing position.
Only available when you apply the parking brake.
DD
Upright 1 Places the product into the Upright 1 position
EE
Upright 2
Places the product into the Upright 2 position and
extends the footrest
FF Recline Lowers the backrest and tilts the seat back
GG Full-Flat Transfer
Places the product into a flat position for transfer to or
from a bed or stretcher
HH Trend
Places the product into the Trend position (head down
with foot up)
II
Chair position indicator
Follows the chair’s position status from one position to
another
JJ
Seat height up Raises the seat height
KK
Seat height down Lowers the seat height
LL
Occupant control lock/unlock
Lock illuminates white when you lock the occupant
control panel. Unlock illuminates white when you
unlock the occupant control panel.
MM
Parking brake status indicator
Lock illuminates white when you apply the parking
brake. Unlock flashes white when you release the
parking brake.
NN
Battery charging indicator (option) Illuminates to indicate that the battery is charging
OO
Battery status indicator (option) Indicates the charge left in the battery
PP
Power indicator
Illuminates when the product is powered
QQ
Diagnostics indicator
Illuminates when in diagnostics mode. Unplug product
and call maintenance.
RR Service indicator
Power the product off, then power the product back on
(
Powering the product on and off
(page 11)). If indicator
is off, continue normal operation. If indicator
illuminates, unplug product and call maintenance.
3333-009-001 Rev H.1 15 EN
