pg 9
A
Parallel - Enables two reverbs and routes your input signal
separately into each, so that neither reverb affects the other�
Note that, when using stereo output, the output of each
reverb can be panned left or right independently using the Pan
parameter� See page 20 for Pan details�
RIGHT IN
LEFT IN
RIGHT OUT
LEFT OUT
+
Reverb 1
Reverb 2
Parallel
B
Series 1
▶▶
2 - Enables two reverbs and routes your input
signal first into Reverb 1 and the Reverb 1 output into the
input of Reverb 2� This functionality is the same as running
one reverb pedal into another reverb pedal�
RIGHT IN
LEFT IN
RIGHT OUT
LEFT OUT
+
+
Reverb 1 Reverb 2
Series 1
▶▶
2
C
Series 1
◀◀
2 - Enables two reverbs and routes the input
signal first into Reverb 2 and the Reverb 2 output into the
input of Reverb 1� This functionality is the same as Series
1
▶▶
2, except with the order reversed�
