Stuart Turner Mainboost MJ3 VM - Checklist

- 5 –
CHECKLIST
Item Description Qty Item Description Qty
Package
1a
1 Monobloc unit 1
Package
2
1 Mainsboost vessel 1
2 ¼ “ BSP Pressure gauge 2
Package
3
1 Pump 1
3 Lever isolating ball valve 1 2 Manifold Assy 1
4
Mainsboost vessel
connector fitting
1 3 Hose 2
5
22/28mm compression
adaptor
2 4 Sealing washer 2
5
Pump mounting
bolt assemby
1 set
6
Pump mounting
bolt assembly
1 set
Your product may vary slightly from the illustrations above.
Mainsboost Charger MJ3 (Vertical) + Mainsboost Monobloc 22/28mm ULK
IMPORTANT: Your Mainsboost Charger MJ3 system will be delivered in a minimum of
three boxes on one pallet. Please check the contents within 24 hours of receipt and
if any component is damaged, please contact Stuart Turner Ltd immediately.
Package 2
Mainsboost vessel
Fig. 3
1
Package 1a
Monobloc 22/28mm Upstream line-in kit
Fig1a
Package 3
MJ3 pump
Fig. 2
4
3
2
1
5
6
5
4
2
3
1
