Stuart Turner MAINSBOOST VariQ - Pump Model Specifications

Cont ...
- 19 -
Pump Model
VariQ
General Warranty 2 years
Features
Pump type Centrifugal Multistage
Pump control Pressure/flow switch
Inlet strainer(s) Optional
Flexible hoses Optional
Dry run protection 
Priming vent plug

Self priming

Typical noise 66 dB(A)
Materials
Pump body Stainless steel
Impeller Plastic
Mechanical seal EDPM / Carbon / Ceramic
Performance
Maximum head - closed valve 55 metres
Performance @ 60 l/min 20.4 metres
Performance @ 80 l/min 10.2 metres
Maximum flow 97 l/min
Maximum static inlet pressure 10 metres
Maximum static outlet pressure 12 metres
Maximum working pressure* 650 kPa (6.5 bar)
Max. ambient air temperature (continuous) 40°C
Min / Max water temperature Min 4°C / Max 60°C
Max. suction lift* 4 metres
Connections Pump connections G1 female
Motor
Type Permanent magnet variable frequency
Duty rating Continuous (S1)
Electrical
Power supply (Vac/Ph/Hz) 230 V a.c. / 1 / 50 Hz
Power consumption - P1 665 Watts
Current- full load 2.9 Amps
Fuse rating 5 Amps
Power cable length 1.5 metres
Phy
#sical
Enclosure protection IPX4
Length 391 mm
Width 194 mm
Height - excluding hoses 292 mm
Weight - including fittings 9 Kg
*Note: A suction lift of up to 4 metres can be achieved if a footvalve and strainer is used.
