Studer Innotec SA
BSP
8 V1.0.3 User Manual
The exponent n
peukert
varies in every battery and is on average approximately 1.25. C
ref
and I
ref
refers to
the given capacity at a known current.
Discharge speed Capacity at C10 (100 Ah at 10 A during 10 hours)
C3 0.74
C20 1.19
C50 1.50
C100 1.78
Table 1.1. Capacity ratio with a Peukert exponent of 1.25
1.1.5. Capacity over the battery lifetime
The capacity decreases along the charge-discharge cycles. The deep discharges have a particularly negative
impact. High ambient temperatures lower also the lifetime.
1.2. Conventions
1.2.1. Symboles
This symbol is used to indicate the presence of a dangerous voltage that is sufficient
to constitute a risk of electric shock.
This symbol is used to indicate a risk of material damage.
This symbol is used to indicate information that is important or which serves to optimize
your system.
1.2.2. Regarding the parameters
All values mentioned hereafter, followed by a parameter number indicate that this value may be modified
using the RCC-02/-03 remote control. In general, the default values are not mentioned and are replaced by
a parameter number in the following format: {xxxx}. The default values for this parameter are specified in the
defaults parameter table Chapter 8: “ Factory setting values ” (p. 23) .
1.3. Warranty and liability
1.3.1. Warranty and liability
During production and assembling, each BSP gets several controls and tests. They are carried out in full
respect of fixed procedures. Each BSP is given a serial number allowing a perfect follow-up of the controls,
in conformity with the specific data of every device. For this reason, it is very important to never remove the
descriptive sticker bearing the serial number. The production, the assembling and the tests of each BSP are
entirely carried out in our factory in Sion (CH). The warranty of this product depends on strictly following the
instructions in this manual. The warranty period for the BSP is 5 years.
