Stulz Air Booster 2 - Light Duty Grille (ACTBALDG) Specifications; Heavy Duty Grille (ACTBAHDG) Specifications

36
AIR BOOSTER 2
EN/10.2018/IT30I © STULZ SpA – all rights reserved
12.1. Light duty grille - ACTBALDG
Technical data
Weight 12,1 kg
Thickness 20 mm
Height adjustment 23  44 mm
Concentrated load over 25 mm x 25 mm 1,5 kN
Width 598 mm
Height 598 mm
Threaded pins M830 or M820 (for different height regulation)
Colour RAL 7047
Material Steel
Floor grille structural class EN 13264:2001
12.2. Heavy duty grille - ACTBAHDG
Technical data
Weight 18,9 kg
Thickness 30 mm
Height adjustment 33  44mm
Concentrated load over 25 mm x 25 mm 4,5 kN
Width 598 mm
Height 598 mm
Threaded pins M820
Colour RAL 7047
Material Steel
Floor grille structural class EN 13264:2001
