Stulz Air Booster 2 - Grille Handling and Placement Steps

38
AIR BOOSTER 2
1 - ACTBALDG
2 3
1 - ACTBAHDG
EN/10.2018/IT30I © STULZ SpA – all rights reserved
1. Take the lifting key/keys
2. Hook the lifting key/keys to the grille (picture number 1).
3. Lift and move the grille (picture number 2).
4. Put the grille on the floor (picture number 3).
INFORMATION
Inside the packaging of the fan module, one lifting key is present.
