Stulz ASU series - Page 61

9
Baugröße 1 2 3 4 5 7
A mm 950 1400 1750 2200 2550 3110
B mm 92 145 247 282 257 237
C mm 675 1005 1400 750 950 1200
D mm 210 260 258 210 195 185
E mm 600 550 550 600 600 675
F mm - - - 1342 1492 1805
G mm - - - 750 950 1200
H mm 175 175 175 120 120 120
J mm - - - 260 245 350
K mm - - - 550 550 510
ASD...CW
© STULZ GmbH – all rights reserved EN/11.2016
air side connection
Flexible connection height for all units: 150 mm
Cabinet size
11.3.8 Recessed rear wall
For better flow dynamics Downflow units can be equipped with a rear wall which is recessed by 50 mm.
1 2 3 4 5 7
950 1400 1750 2200 2550 3110
174 250 247 220 257 228
600 1000 1400 750 950 1200
210 300 258 210 195 185
550 510 550 600 600 675
- - - 1342 1492 1805
- - - 750 950 1200
120 120 120 120 120 120
- - - 260 245 350
- - - 550 550 510
ASD...CW2
