Stulz CompTrol 1002 - Page 26

E/0310/50/26
Control Diagram for Units with Compressor
Temperature Control Diagram
1. Compressor 2. Compressor
Numbers refer to the menu items.
Temperature
too low
Temperature
too high
Setpoint
Humidity Control Diagram
Humidity
too high
Setpoint
Humidity
too low Humidification Dehumidification
rel. hum.
Reheat 1Reheat 2
