8. Specifications of the Extension Card 1b
Characteristics
With the extension card 1b, additional inputs and outputs are provided for the CompTrol 1002. The
extension card 1b is fixed on the CompTrol 1002 by means of the two distance pieces enclosed.
Electric connection to the basic board is made by a 20 pins plug connector. As soon as the extensi-
on card has been connected, the alarms aux 2 / fire and smoke detector and Ultrasonic humidifier
5µS/cm can only be detected on the extension board.
Operating Elements (DIP Switches 1-6)
DIP-Switch 1
Configuration of a damper
ON: A damper is configured. Fan start is delayed by approxi
-
mately 90 s.
OFF: A damper is not configured. The fan starts immediately.
DIP-Switch 2 Configuration of a second compressor.
ON: A second compressor is available. The DIP switch
on the rear side of the CompTrol 1002 must be set to OFF
(Compressor version).
OFF: A second compressor does not exist.
DIP-Switch 3-6 No function
All DIP switches on the extension card 1b must only be switched
when no voltage is applied!
