Stulz CompTrol 1002 - CompTrol 1002 Specifications; Technical Data

E/0310/50/27
7. Specification CompTrol 1002
7.1 Technical Data
280 x 195 x 45 mm (11.0" x 7.7" x 1.8")
(24 V + 20 % / - 15 %) V AC
X10, X11.1 grounded
12 W
1 Amp
15 V DC, 40 mAmp
2 (0..20 mAmp)
330 Ohm
162 Ohm
4-Digit LED-display
4 LED green for status
φ 3 mm (1/8")
1 LED red for alarm φ 3 mm (1/8")
4 keys
RS 485 9600 Baud
2 x relays 3 Amp, 24 V,1 normally open for alarm,
humidification
5 x triac 4 Amp, 24 V
fan, valve or compressor and dehumidification saver
circuit, reheat 1, reheat 2
The consumer is connected to 24V.
8 x 24 V AC
2.7 kOhm input resistance
0°C ... 40°C (32°F ... 104°F)
-10°C ... 60°C (14°F ... 140°F)
Dimensions L x W x H
Power supply
Power consumption
Fuse
Power output
Sensor input
Operating resistance "temperature"
Operating resistance "humidity"
Display
Service elements
Interface for BMS (Building Management
System)
Outputs
Inputs
Operating temperature
Storage temperature
