E/0310/50/30
7.3 Bus connection
C1002 board with driver module
Driver module
The C1002 controller can be integrated in the Stulz bus. The driver module serves to properly
adjust the C1002 as a bus participant in dependence of the position within the bus. For a detailed
description of the driver module see next page.
Low, terminal 32
High, terminal 33
RS 485, for Stulz bus connection
