33 © STULZ S.p.A. – all rights reserved EN/06.2016/i01
WPA EXPLORER ORIGINAL INSTRUCTIONS
Free Cooling - three V-modules (WPA 080-090-100-110)
FL, RA, RE on the storage tank available as options.
Standard circuit diagram. Check MANUAL PART IIa for any changes.
QUICK COUPLING (Victaulic
®
)
WPA 080 090 100 110
Ø / Type 3” M 3” M 4” M 4” M
