ULTRASONIC
47
Copyright STULZ GmbH 02/1997
ASSEMBLY ENS SERIES
Ultrasonic humidifiers of ENS series can be used for laminar flows at air
speeds between 1.5 and 3 m/s. Should this air speed be exceeded, a
perforated plate has to be installed in front of the air inlet of the humidifier
(illustration no. 1). The perforated plates reduce the free cross section by
more than 60% and therefore reduce the air speed through the humidifier
in a very efficient way. For installation of the perforated plate, an angle
section (illustration no. 2 and 3) is fastened to humidifier's assembly screw
connection, where the perforated plate is then fixed to.
