Built-In Refrigeration 23
subzero.com/specs
Flush Inset Opening Widths A B
BI-36R, BI-36RG and BI-36F 35
1
/2" (902) 38" (965)
BI-30U and BI-30UG 29
1
/2" (746) 32" (813)
BI-36U, BI-36UG and BI-36UFD 35
1
/2" (902) 38" (965)
BI-36S 35
1
/2" (902) 38" (965)
BI-42S, BI-42SID and BI-42SD 41
1
/2" (1054) 44" (1118)
BI-48S, BI-48SID and BI-48SD 47
1
/2" (1206) 50" (1270)
UNIT WITH
3
/4" (19) PAN EL
DETAIL A
DETAIL B
FRONT VIEW
A
WIDTH TO CLEAT
B
FLUSH INSET WIDTH
1
1
/4"
(32)
1
1
/4"
(32)
SIDE VIEW
84"
(2134)
FLUSH
INSET
HEIGHT
1
/4"
(6)
24" (610)
DEPTH TO CLEAT
26
3
/16" (665)
FLUSH INSET DEPTH
2
3
/16"
(56)
83
3
/4"
(2127)
HEIGHT
TO CLEAT
24" (610)
DEPTH
TO CLEAT
26
3
/16"
(665)
FLUSH
INSET
DEPTH
TOP VIEW
2
3
/16"
(56)
1
1
/4"
(32)
CLEAT
CLEAT
Detail A
Detail B
1
1
/ 4 "
(32)
24" (610)
OPENING
DEPTH
TO CLEAT
CLEAT
TOP VIEW
26
3
/ 16 "
(665)
FLUSH
INSET
DEPTH
2
3
/ 16 " (56)
3" (76)
typical
24" (610)
OPENING
DEPTH TO
CLEAT
1
1
/ 4 "
(32)
2
3
/ 16 " (56)
CLEAT
SHADED
AREA
MUST BE
FINISHED
3" typical
(76)
4" (102)
Built-In Models
FLUSH INSET INSTALLATION
Dimensions assume a
3
/4" (19) panel thickness.
IMPORTANT NOTE: If an 83"
(2108) grille height is specified,
the height to cleat and flush inset height must be decreased
by
7
/8" (22).Ifan88"(2235) grille height is specified, the height
to cleat and flush inset height increases by 4"
(102).
If two units are installed side by side, refer to pages 32–36 for
dual flush inset installations.
