Built-In Refrigeration 36
Dual Installation Kit
INSTALLATION WITH DUAL WIDE GRILLE
This kit will replace the existing grilles that ship with the
units and span the entire width of both units. The kit
includes a
1
/4" (6) center trim strip (required for proper
installation of the dual wide grille), heater, dual kickplate
and mounting hardware. Dual wide grilles are available for
all built-in models and design applications. The overlay
dual installation kit with grille will accept overlay and dual
flush inset panels. For dual wide grille panel dimensions,
refer to the panel specifications below for your design
application. Grille panel dimensions listed are for a
standard 84"
(2134) finished height.
INSTALLATION WITH INDIVIDUAL GRILLES
This kit is available for those who choose to utilize the
individual grilles that ship with each unit. The kit includes a
1
/4" (6) filler strip (which fills the reveal between the units
and grilles), heater and mounting hardware. This dual
installation kit is not required if a custom filler strip is used.
The filler strip should be a minimum of 2"
(51) wide. Refer
to the full-scale template on page 42 for more information.
Dual Wide Grille—Overlay
TWO 30" (762) MODELS W H
Overlay Panel 60
1
/4" (1530) 9
1
/4" (235)
Spacer Panel 59
3
/8" (1508) 8
5
/16" (211)
Backer Panel 60" (1524) 8
15
/16" (227)
30" (762) AND 36" (914) MODELS W H
Overlay Panel 66
1
/4" (1683) 9
1
/4" (235)
Spacer Panel 65
3
/8" (1661) 8
5
/16" (211)
Backer Panel 66" (1676) 8
15
/16" (227)
TWO 36" (914) MODELS W H
Overlay Panel 72
1
/4" (1835) 9
1
/4" (235)
Spacer Panel 71
3
/8" (1813) 8
5
/16" (211)
Backer Panel 72" (1829) 8
15
/16" (227)
Dual Wide Grille—Flush Inset
TWO 30" (762) MODELS W H
Flush Inset Panel 61
1
/4" (1556) 9
1
/4" (235)
Spacer Panel 59
3
/8" (1508) 8
5
/16" (211)
Backer Panel 60" (1524) 8
15
/16" (227)
30" (762) AND 36" (914) MODELS W H
Flush Inset Panel 67
1
/4" (1708) 9
1
/4" (235)
Spacer Panel 65
3
/8" (1661) 8
5
/16" (211)
Backer Panel 66" (1676) 8
15
/16" (227)
TWO 36" (914) MODELS W H
Flush Inset Panel 73
1
/4" (1861) 9
1
/4" (235)
Spacer Panel 71
3
/8" (1813) 8
5
/16" (211)
Backer Panel 72" (1829) 8
15
/16" (227)
