Sub-Zero BI-36UFD - Page 41

Built-In Refrigeration 41
subzero.com/specs
1
1
/4" (32)
ASSUMES
3
/4" (19)
FLUSH INSET
PANEL
THICKNESS
2
3
/16" (56)
24" (610)
TO BACK WALL
3
/4" (19) THICK
FLUSH INSET PANEL
(TYPICAL)
1
/4" (6) BACKER
PANEL
1" (25) THICK
PANEL
Flush Inset Application
FULL-SCALE TEMPLATE
For panels thicker than
3
/4" (19),
a 90° door stop may be required
to prevent interference with
adjacent cabinets.
DOOR OPENING 110°
TOP VIEW
1" (25)0"
SCALE
