Built-In Refrigeration 42
1
1
/4" (32)
FILLER STRIP
APPROX PROFILE OF
STAINLESS STEEL WRAPPED
DOOR AND HANDLE
DOOR
OPEN 110°
DOOR
CLOSED
Dual Installation—Standard
FULL-SCALE TEMPLATE
Typical framed, overlay or stainless steel
dual installation with filler strip at
maximum 110° door opening. Depending
on panel thickness, a 90° door stop may
be required.
STANDARD
TOP VIEW
1" (25)0"
SCALE
