Wine Storage 73
subzero.com/specs
Panel Requirements
MIN WIDTH
Stiles 2
1
/4" (57)
Top Rail 3
3
/4" (95)
Bottom Rail (427G) 8" (203)
Bottom Rail (427RG) 3" (76)
MAX PANEL WEIGHT
Door Frame 20 lbs (9 kg)
Drawer Panel (427RG) 12 lbs (5 kg)
MIN PANEL THICKNESS
All Panels
5
/8" (16)
Integrated Panels
427G W H
Door 26
3
/4" (679) 75
7
/8" (1927)
427RG W H
Door 26
3
/4" (679) 45
3
/8" (1153)
Top Drawer 26
3
/4" (679) 13
9
/16" (345)
Bottom Drawer 26
3
/4" (679) 16
11
/16" (424)
Integrated Panels
MODELS 427G AND 427RG
The integrated full panels or frame panels for glass doors
for these models will follow some of the identical planning
processes used with the integrated line. The installation of
the door panels is completely different, however. Rather
than using the mounting hardware we used with the inte-
grated line, door panels for both models 427G and 427RG
will be applied with screws applied through our door.
The drawer panels for the model 427RG will be applied
using the integrated technique of mounting brackets.
IMPORTANT NOTE: The depth of models 427G and
427RG is 24"
(610) from the front of the unit to its back.
You must allow for the thickness of the panel you are
applying when planning for the finished rough opening
depth if you want the front panel to be flush with sur-
rounding cabinetry. You may have to move the unit back
into the drywall or bring the cabinets forward. Refer to the
integrated section.
Panel dimensions listed in the chart assume the models
finish off at 80"
(2032) in height overall and have a 4" (102)
toe kick for the model 427G. If you finish off at 84" (2134),
for instance, you must add an additional 4"
(102) to the
finished height of the panel and 4"
(102) to the top rail.
Likewise, if you allow for a 6"
(152) toe kick for the model
427G, you must subtract 2"
(51) from the bottom rail.
The height of the door panel for models 427G and 427RG
can extend beyond the typical panel height, provided you
do not exceed the panel weight limit. Refer to specifica-
tions on page 59 of the integrated section.
The toe kick area on model 427G cannot be larger than 6"
(152), and on model 427RG, no larger than 9" (229). The toe
kick area for either model cannot be less than 4"
(102).
If you are installing an optional lock kit on models 427G
or 427RG, you may have to order door panels that exceed
the 80"
(2032) finished height. Consult the lock kit installa-
tion instructions and see if your panels will allow for an
adequate installation. These instructions are available on
our website, subzero.com.
DUAL INSTALLATIONS
For information on dual installations for models 427G and
427RG, refer to the integrated dual installations section on
page 61.
