Undercounter Refrigeration 89
subzero.com/specs
Overlay Panel
MODELS UC-24R, UC-24C(I) AND UC-15I(P)
The overlay design allows for a decorative panel to cover
the door trim for a seamless appearance that will comple-
ment surrounding cabinetry. You may also choose to
match the handle hardware of surrounding cabinetry.
Refer to the charts for panel specifications.
MODEL UC-24BG
For model UC-24BG, the overlay door panel will consist of
only a frame and will affix directly to the door with screws
through a series of predrilled holes.
The glass area of the door is designed to be exposed to
air circulation. Decorative overlays on the glass should be
kept to a minimum. Do not install a solid panel on the
glass door unit: this may cause moisture to form behind
the panel. Refer to the charts for panel specifications.
IMPORTANT NOTE: The width of rails and stiles can be
increased but should not exceed cabinet manufacturers’
standard widths or the overall panel dimensions. The back
sides of rails and stiles that will be visible through the
glass door will need to be finished along with the inside
edges of the frame.
Panel Requirements
MAX PANEL WEIGHT
UC-24R and UC-24C(I) 20 lbs (9 kg)
UC-24BG 10 lbs (5 kg)
UC-15I(P) 15 lbs (7 kg)
MIN PANEL THICKNESS
Overlay Panels
5
/8" (16)
Panel Dimensions
UC-24R AND UC-24C(I) W H
Overlay Panel 23
3
/4" (603) 30
1
/16" (764)
UC-24BG W H
Overlay Panel 23
3
/4" (603) 30
1
/16" (764)
Rails and Stiles (min) 2
1
/4" (57)
UC-15I(P) W H
Overlay Panel 15" (381) 30
3
/8" (772)
Door Clearance
MODELS UC-24R, UC-24BG AND UC-24C(I)
Undercounter models can be installed flush with surround-
ing cabinetry. Depending on the thickness of the overlay
door panel, it may be necessary to install the unit so that it
extends
1
/4" (6) beyond the front surface of surrounding
cabinetry. This will prevent interference between the door
panel and adjoining cabinetry at the maximum 145° door
swing. Refer to the full-scale template on page 83 of the
wine storage section.
