Undercounter Refrigeration 90
Accessories
These optional accessories are available through your
authorized Sub-Zero dealer. For local dealer information,
visit the find a showroom section of our website,
subzero.com.
• Stainless steel front panel with tubular or pro handle.
• Stainless steel tubular and pro handles to match the
style of Wolf ovens and ranges.
• UL approved door lock.
STANDARD HANDLES
Refer to the chart below for standard handle lengths and
the stud spacing of tubular and pro handles used on
undercounter models.
Glass
C
L
1"
(25) 1" (25)
2
1
/4" (57) Rail/Stile
Door Panel Profile
Door Frame Profile
FULL-SCALE TEMPLATE
The full-scale template shows the door frame profile for
model UC-24BG and the relationship to the overlay panel
(rails and stiles).
DOOR FRAME PROFILE
MODEL UC-24BG
Standard Handles Length Stud Spacing
UNDERCOUNTER MODELS
Tubular Handle 24
3
/16" (614) 16
1
/4" (413)
Pro Handle 21" (533) 19
11
/16" (500)
