Sub-Zero Built-In Refrigeration User Manual

Panel Installation 30
Overlay Panel Specifications
BI-36R / BI-36F BI-36RG BI-30U / BI-36U BI-30UG / BI-36UG
HH
A
W
H
A A
B
W
H
A
A A
H
W
H
A
H
H H
W
H
*Panel height may be increased by
1
/2" (13) to hide upper
main frame. For more information, refer to the built-in panel
configurator at subzero.com/trade/panels.
Grille panel dimensions listed are for a standard 84" (2134)
overall height of the unit. For an 83" (2108) overall height,
subtract 1" (25) from grille panel height dimensions. For an
88" (2235) overall height, add 4" (102) to height dimensions.
Width dimensions do not vary.
Models BI-30U and BI-30UG
REFRIGERATOR WH
Overlay Panel 30" (762) 50
1
/8" (1273)
Spacer Panel 29
1
/8" (740) 49
5
/16" (1253)
Backer Panel 29
3
/4" (756) 49
15
/16" (1268)
FREEZER WH
Overlay Panel 30" (762) 19" (483)
Spacer Panel 29
1
/8" (740) 18
1
/16" (459)
Backer Panel 29
3
/4" (756) 18
11
/16" (475)
GRILLE WH
Overlay Panel 30" (762) 9
1
/4" (235)*
Spacer Panel 29
1
/8" (740) 8
5
/16" (211)
Backer Panel 29
3
/4" (756) 8
15
/16" (227)
BI-30UG WH
Window Cut-Out 19
1
/2" (495) 39
5
/8" (1006)
A
Cut-Out Location 5
1
/4" (133)
Models BI-36R, BI-36RG and BI-36F
REFRIGERATOR/FREEZER WH
Overlay Panel 36" (914) 69
3
/4" (1772)
Spacer Panel 35
1
/8" (892) 68
15
/16" (1751)
Backer Panel 35
3
/4" (908) 69
9
/16" (1767)
GRILLE WH
Overlay Panel 36" (914) 9
1
/4" (235)*
Spacer Panel 35
1
/8" (892) 8
5
/16" (211)
Backer Panel 35
3
/4" (908) 8
15
/16" (227)
BI-36RG WH
Window Cut-Out 25
1
/2" (648) 54
1
/8" (1375)
AB
Cut-Out Location 5
1
/4" (133) 10
3
/8" (264)
Models BI-36U and BI-36UG
REFRIGERATOR WH
Overlay Panel 36" (914) 50
1
/8" (1273)
Spacer Panel 35
1
/8" (892) 49
5
/16" (1253)
Backer Panel 35
3
/4" (908) 49
15
/16" (1268)
FREEZER WH
Overlay Panel 36" (914) 19" (483)
Spacer Panel 35
1
/8" (892) 18
1
/16" (459)
Backer Panel 35
3
/4" (908) 18
11
/16" (475)
GRILLE WH
Overlay Panel 36" (914) 9
1
/4" (235)*
Spacer Panel 35
1
/8" (892) 8
5
/16" (211)
Backer Panel 35
3
/4" (908) 8
15
/16" (227)
BI-36UG WH
Window Cut-Out 25
1
/2" (648) 39
5
/8" (1006)
A
Cut-Out Location 5
1
/4" (133)
