Component Removal
M Series Wall Oven
M Series Wall Oven
3-17
#824974 - Revision C - November, 2016
Figure 3-38. Back of Alternate Cooling Unit
Figure 3-37. Back of Alternate Cooling Unit
Alternate Cooling Changes
Serial # Break:
Single Oven: 16219812 - 16219842, and above 16223239
Double Oven: 16228579 - 16228656, and above 16230892
Above the serial number break the cooling fan system
was modified. Figures 3-37 and 3-38 show the general
lay out of the single and double oven with the upper
cover removed.
