IMPREZA(NA) A1850BE-A (ENGLISH)
Keys and doors
2-18
B To enter the passive mode
1. Remove the side sill cover on the driver’s side.
1)Open the driver’s door.
2)Remove the two clips fastening the front portion
of the cover with a screwdriver.
3)Remove the side sill cover by pulling it up.
1) Connector for SRS airbag system (yellow)
2) White (1P)
2. Connect the white (1 pole) connector.
3. Turn the ignition switch from the “LOCK” to the
“ON” position.
4. Install the side sill cover.
To place the system in active arming mode (remote
required for activation), disconnect the white con-
nector.
