IMPREZA(NA) A1850BE-A (ENGLISH)
11
Maintenance and service
11-31
– CONTINUED –
Rear differential gear oil
J Checking the gear oil level
Your vehicle may be equipped with a rear differential
protector. The differential protector provides protec-
tion to the rear differential assembly during off-road
use. Removal of the rear differential protector is not
required when checking the oil level.
1) Filler plug 2) Drain plug
1) Filler hole
2) Drain hole
3) Oil level
Remove the plug from the filler hole and check the
oil level. The oil level should be kept even with the
bottom of the filler hole. If the oil level is below the
bottom edge of the hole, add oil through the filler
hole to raise the level.
CAUTION
If the vehicle requires frequent refilling, there
may be an oil leak. If you suspect a problem,
have the vehicle checked at your SUBARU
dealer.
To Next Page
