IMPREZA(NA) A1850BE-A (ENGLISH)
11
Maintenance and service
11-37
– CONTINUED –
Brake pedal
Check the brake pedal free play and reserve dis-
tance according to the maintenance schedule in the
“Warranty and Maintenance Booklet”.
J Checking the brake pedal free play
1) 0.04 – 0.12 in (1.0 – 3.0 mm)
Stop the engine and firmly depress the brake pedal
several times. Lightly press the brake pedal down
with one finger to check the free play with a force of
less than 2 lb (10 N, 1 kg).
If the free play is not within proper specification,
contact your SUBARU dealer.
J Checking the brake pedal reserve dis-
tance
1) More than 2.56 in (65 mm)
Depress the pedal with a force of approximately 66
lb (294 N, 30 kg) and measure the distance be-
tween the upper surface of the pedal pad and the
floor.
When the measurement is smaller than the specifi-
cation, or when the pedal does not operate smooth-
ly, contact with your SUBARU dealer.
