北米Model "A1470BE-A" EDITED: 2021/ 8/ 2
11-20. Fuses
S11BB
CAUTION
Never replace a fuse with one having
a higher rating or with material other
than a fuse because serious damage
or a fire could result.
NOTE
Fuse rating and using circuit are de-
scribed on each behind the fuse box
cover.
The fuses are designed to melt during an
overload to prevent damage to the wiring
harness and electrical equipment. The
fuses are located in two fuse boxes.
One is located under the instrument panel
behind the fuse box cover on the driver’s
seat side. To remove the cover, pull it out.
1) Spare fuses
The other one (main fuse box) is housed in
the engine compartment. Also, the spare
fuses are stored in the fuse box cover.
The fuse puller is stored in the main fuse
box in the engine compartment.
Pinch the upper part of the fuse puller
when removing it from the main fuse box.
1) Good
2) Blown
Fuses
454
