Subaru EH90 - Wiring Diagram

17
WIRING DIAGRAM
M
S
G
B
L
30AMP FUSE
BLUE
HIGH TEMPERATURE
WARNING ALARM
WHITE
WHITE
YELLOW
TACHOMETER/ HOUR METER (OPTION)
SPARK PLUG
SPARK PLUG
IG COIL #2
OFF RUN
IG COIL #1
KEY SWITCH(OPTION)
ORANGE
RED
BLACK
BLACK
CHARGE COIL
REGULATOR
STARTING MOTOR
BATTERY
RED
SWITCH
OIL PRESSURE
WHITE
LOW OIL WARNING LAMP
12V-30AH
MB L SG
CARBURETOR
YELLOW
BLUE
YELLOW
START
STOP
DIODE
STOP
DIODE
IGNITION KILL
BLACK
BLACK
BLACK
HIGH TEMPERATURE SENSOR - 293°F
YELLOW
