. Airbag control module (including im-
pact sensor)
. Frontal airbag module
– Driver’s side
– Front passenger’s side
. Knee airbag module (driver’s side – if
equipped)
. Side airbag sensor (if equipped)
– Center pillar right-hand side
– Center pillar left-hand side
. Side airbag module (if equipped)
– Driver’s side
– Front passenger’s side
. Front passenger’s occupant detection
sensor (if equipped)
. Front passenger’s occupant detection
control module (if equipped)
. Seatbelt buckle switch (front passen-
ger’s side – if equipped)
. Curtain airbag sensor (if equipped)
– Rear wheel house right-hand side
– Rear wheel house left-hand side
. Curtain airbag module (if equipped)
– Right-hand side
– Left-hand side
. Satellite safing sensor (under the rear
center seat – if equipped)
. Seatbelt pretensioner
– Driver’s side
– Front passenger’s side
. All related wiring
WARNING
If the warning light exhibits any of
the following conditions, there may
be a malfunction in the seatbelt
pretensioners and/or SRS airbag
system. We recommend that you
have the system checked immedi-
ately by your nearest SUBARU deal-
er. Unless checked and properly
repaired, the seatbelt pretensioners
and/or SRS airbags will operate
improperly (e.g. SRS airbags may
inflate in a very minor collision or
not inflate in a severe co llision),
which may increase the risk of
injury.
. Flashing or flickering of the warn-
ing light
. No illumination of the warning
light when the ignition switch is
first turned to the “ON” position
. Continuous illumination of the
warning light
. Illumination of the warning light
while driving
& SRS airbag system servicing
WARNING
. When discarding an airbag mod-
ule or scrapping the entire vehi-
cle damaged by a collision, we
recommend that you consult
your SUBARU dealer.
. The SRS airbag has no u ser-
serviceable parts. Do not use
electrical test equipment on any
circuit related to the SRS airbag
system. For required servicing of
the SRS airbag, we recommend
that you consult your nearest
SUBARU dealer. Tampering with
or disconnecting the system’s
wiring could result in accidental
inflation of the SRS airbag or
could make the system inopera-
tive, which may result in serious
injury.
CAUTION
If you need service or repair in areas
indicated in the following list, we
recommend that you have the work
performed by an authorized
SUBARU dealer. The SRS airbag
control module, impact sensors
Seat, seatbelt and SRS airbags/*SRS airbag (Supplemental Restraint System airbag) 1-63
