SUEX XK - TECHNICAL SPECIFICATIONS; NOISE AND VIBRATIONS; TRANSPORT OF THE LI ION BATTERY

Rev.05 – 03/02/2021
Pag. 33/37
Cede: 71382
29. TECHNICAL SPECIFICATIONS
Catacteristic
Unit of measure
Data
Dimension: Lungh. x Largh. x Alt.
mm.
814x436x340
Weight without battery
Kg
14
Weight with battery
Kg.
20
Body diameter
Mm
197
Max speed
m/min.
85
Run time at max speed
min
35
Run time at cruise speed
min
95
Nominal voltage
V.DC
26,4
Nominal capacity
Wh
370
Max static thrust
N
330
Test depth
mt
300
Autonomy
mt
from 35 to 110
Battery type
NiMh
Maximum recharging time
h
4,5
Trim
neutral
Maximum operational depth
m
200
Materiali costruttivi
Aluminum body
Suitable for operating in tropical conditions without requirement of temperature controlled stowage.
Due to constant product development the provided data are subject to changes without prior notice.
29.1. NOISE AND VIBRATIONS
Continuos weigghted-A equivalent sound pressure level does not exceed 70 dB (A).
Weighted-C peak sound pressure value does not exceed 63 Pa (130dB in relation to 20 microPa).
The average weighted square root of acceleration transmitted to the hand-arm system does not exceed 2,5 m/s2.
30. TRANSPORT OF THE LI ION BATTERY
TRANSPORT OF THE BATTERY OUT OF THE SCOOTER
In order to transport a Li-ion battery (alone), out of the SCOOTER a specific packaging must be used.
Battery cannot be transported by air on a passenger craft, it can be air shipped on an AIR CARGO only.
The Li-ion battery is class 9 classified for transportation
Refer to UN3480 and IATA packaging instructions PI-965.
Refer to your forwarder for detailed information.
