4500P- 7500 USER MANUAL SECTION 3
24
3.2 TABLE OF SPECIFICATIONS - VARIABLE SPEED DRIVE
VSD SERIES (I) - 4500PV (MODELS 4507PV - 4509PV)
MOTOR ODP TEFC
HZ/VOLTAGE 460/60 575/60 400/50 460/60 575/60 400/50
DRIVE AMP
RATING
87 80 105 87 80 105
WEIGHT (lbs/kg) 2755/1250 3097/1404 3010/1365 3300/1497 3445/1503 3420/1551
LENGTH (in/mm) 78.7/1999 78.7/1999 78.7/1999 78.7/1999 78.7/1999 78.7/1999
WIDTH (in/mm) 43.3/1100 43.3/1100 43.3/1100 43.3/1100 43.3/1100 43.3/1100
HEIGHT (in/mm) 68.9/1750 68.9/1750 68.9/1750 68.9/1750 68.9/1750 68.9/1750
VSD SERIES (I) - 5500V (MODELS 5507V - 5512V)
MOTOR ODP TEFC
HZ/VOLTAGE 460/60 575/60 400/50 460/60 575/60 400/50
DRIVE AMP
RATING
105 100 140 105 100 140
WEIGHT (lbs/kg) 2963/1344 3168/1437 3014/1367 3281/1491 3492/1584 3338/1514
LENGTH (in/mm) 78.7/1999 78.7/1999 78.7/1999 78.7/1999 78.7/1999 78.7/1999
WIDTH (in/mm) 43.3/1100 43.3/1100 43.3/1100 43.3/1100 43.3/1100 43.3/1100
HEIGHT (in/mm) 68.9/1750 68.9/1750 68.9/1750 68.9/1750 68.9/1750 68.9/1750
VSD SERIES (I) - 7500V (MODELS 7509V - 7512V)
MOTOR ODP TEFC
HZ/VOLTAGE 460/60 575/60 400/50 460/60 575/60 400/50
DRIVE AMP
RATING
140 125 170 140 125 170
WEIGHT (lbs/kg) 3341/1515 3535/1603 3391/1515 3531/1601 3752/1690 3531/1601
LENGTH (in/mm) 78.7/1999 78.7/1999 78.7/1999 78.7/1999 78.7/1999 78.7/1999
WIDTH (in/mm) 43.3/1100 43.3/1100 43.3/1100 43.3/1100 43.3/1100 43.3/1100
HEIGHT (in/mm) 68.9/1750 68.9/1750 68.9/1750 68.9/1750 68.9/1750 68.9/1750
(I) Includes standard and 24KT. Rated pressure designations appearing after model number are as follows:
07 - 100 psig (6.9 bar) 10 - 150 psig (10.3 bar)
09 - 125 psig (8.6 bar) 12 - 175 psig (12.0 bar)
Maximum unload pressure is the rated pressure plus 10 psig (0.7 bar).
