E900H User Manual 2: Description
02250203-986 R03
Subject to EAR, ECCN EAR99 and related export control restrictions. 23
2.9 Instrument panel
See Figure 2-5. The compressor is provided with an
instrument panel to monitor an
d control key functions of
the compressor package. To ensure proper operation of
the machine, operators should be familiar with the func-
tion and use of each display and control. See Section
5.2: Purpose of controls on p
age 39 for the details.
Figure 2-5: Instrument panel
