10.2.4 High (Discharge) temperature (Alarm)
What it means: Temperature sensor B3 (compressor discharge temperature) registers a
temperature above 248
o
F (120
o
C).
What it does: Cuts power to compressor contactor & alarm contacts. Turns dryer OFF. Turns on
Warning Light & blinks “Ht” on the digital display.
Possible Causes & Remedies:
1) A low refrigerant charge is causing the refrigerant to absorb too much heat in the
evaporator causing a compressor discharge temperature in excess of 248
o
F.
Remedy – Check or leaks at welds, threaded connections, schrader valve caps,
and joints of the condenser and evaporator. Repair the leak, pull the system to deep
vacuum and charge the dryer with the correct amount of refrigerant as specified in
the Section 2.3.
2) A clogged refrigerant filter is restricting the amount of refrigerant getting to the
evaporator, causing it to absorb too much heat, which causes a compressor
discharge temperature in excess of 248
o
F. This can be confirmed by measuring the
temperature drop across the filter, which should not exceed a few degrees.
Remedy – Replace the clogged component.
3) A clogged capillary tube is restricting the amount of refrigerant getting to the
evaporator, causing it to absorb too much heat, which causes a compressor
discharge temperature in excess of 248
o
F.
Remedy – Replace the clogged component. Pay attention when welding the tube,
not to restrict it or block it with the brazing alloy.
To Reset: Find the cause of the alarm and fix the problem.
Press ALARM RESET to clear alarm. Power restored to alarm relay, Warning Light
goes off. Dryer remains OFF. Display clears.
Press ON/OFF to restart dryer.
Notes: Alarm can only be cleared if the discharge temperature is below 248
o
F (120
o
C).
