Why is my Sulzer Water Pump making excessive noise or vibration?
Excessive noise or vibration in your Sulzer Water Pump can stem from several causes. It could be due to a defective bearing, which would require bearing replacement. Another cause might be a clogged impeller; in this case, you should remove and clean the hydraulics. Also, check for the wrong direction of rotation and change it by interchanging two phases of the power supply cable.
What to do if my Sulzer Water Pump has low head or flow?
If your Sulzer Water Pump exhibits low head or flow, there are a few things to investigate. First, check for the correct direction of rotation and change it by interchanging two phases of the power supply cable if needed. Also, the gap between the impeller and bottom plate might be too wide, reduce the gap. Finally, ensure the gate valve is fully open; a partially open valve can restrict flow.
Why does my Sulzer Water Pump switch on and off intermittently?
Intermittent switching of your Sulzer Water Pump can be attributed to a few reasons. If it's due to a temperature sensor shutdown, the motor will restart automatically once the pump cools down. Also, check the thermal relay settings in the control panel. Impeller blockage can also cause this issue, so inspect for that. If none of these resolve the problem, a service inspection is required.
What to do if the impeller is jammed in my Sulzer Water Pump?
If the impeller of your Sulzer Water Pump is jammed, you should inspect and remove any object causing the jam. Additionally, check the gap between the impeller and the bottom plate, adjusting it if necessary.
What to do if the gate valve is closed or the non-return valve is blocked in my Sulzer Water Pump?
If you find that the gate valve of your Sulzer Water Pump is closed or the non-return valve is blocked, open the gate valve and clean any blockage from the non-return valve.
What to do if there is level control override in my Sulzer Water Pump?
If there is a level control override in your Sulzer Water Pump, check for a float switch that is faulty or tangled and held in the OFF position in the sump.
How to remove air lock in volute of Sulzer Water Pump?
To remove an air lock in the volute of your Sulzer Water Pump, shake or raise and lower the pump repeatedly until resulting air bubbles no longer appear at surface level.
General| Type | Submersible Sewage Pump |
|---|---|
| Maximum liquid temperature | 40°C |
| Rated voltage | 400 V |
| Rated frequency | 50 Hz |
| Number of poles | 2 |
| Protection class | IP68 |
| Speed | 2900 rpm |
| Material | Cast iron |
| Maximum submersion depth | 20 m |
| Outlet Diameter | 80 mm |
| Operating Temperature | 0 to 40°C |
Mandatory personal protective equipment (PPE) requirements for installation, operation, and service.
Lists explosion-proof approvals and standards applicable to Ex-rated motors.
Provides guidance on operating Ex-rated pumps in hazardous areas, including filling and running conditions.
Details safe operation of Ex pumps with frequency inverters in hazardous zones.
Specifies requirements for operating Ex submersible pumps in wet wells without a cooling jacket.
Explains the function and connection of the leakage sensor (DI) for seal monitoring.
Details the function of thermal sensors in the stator windings for overheating protection.
Discusses suitability of motors for frequency inverters and essential operating conditions.
Details the procedure for checking and verifying the correct pump rotation direction.
Instructions for draining and refilling the oil in the seal chamber of PE1 and PE2 pumps.
Step-by-step guide for draining and refilling the seal chamber oil.
Instructions for draining and refilling oil in PE3 pumps without a cooling jacket.
Instructions on how to adjust the bottom plate clearance for optimal pump performance.
Detailed steps for adjusting the bottom plate clearance after wear.
Guidance for operators and service personnel on clearing pump blockages safely.
